100B15 15-Tooth, 100 Standard Roller Chain Type B Sprocket (1 1/4" Pitch)
Regular price
$77.16
Couldn't load pickup availability
This Type B, minimum bore sprocket drives #100 standard roller chain. All of our sprockets are manufactured with hardened steel teeth to improve overall strength and prevent wear and tear on both the sprocket and the chain. CUSTOM BORING AVAILABLE - CALL 1-888-868-5891
Bore Diameter | 1” | Construction | Type B Minimum Bore | Bore Type | Rough Stock Bore |
Length Through Bore | 1 3/4'' | Bushing Bore Range | 1 - 3'' | Application | Power transmission in mechanical drive applications (conveying, lifting, industrial machinery, forestry, etc.) |
Chain Number | 100 | Pitch | 1 1/4'' | Number Of Strands | 1 |
Material | Steel | Outside Diameter | 6.63'' | Pitch Diameter | 6.012'' |
Number Of Teeth | 15 | Thickness | 0.692'' |
