HKK 2-Strand #50 Standard Riveted Roller Chain (0.625" Pitch) - SOLD BY THE FOOT

In stock - 12 items available
$16.25

Standard roller chain is the most common form of chain used in mechanical drive applications. This type of chain is used in a multitude of settings ranging from industrial, to agricultural, to automotive. Heat treatment, shot-peening, and pre-stretching of chain improves its strength and durability and ensures maximum longevity.



*Weight is pounds per foot; chain sold by the foot. You will get a free connecting link for every 10 feet purchased.

Application Industrial, Agricultural, Automotive drives
Pitch 0.625”
Roller Width 0.375”
Height 0.571”
Plate Thickness 1 0.094”
Plate Thickness 2 0.094”
Average Tensile Strength 8,150 LB
Maximum Allowable Load 1,620 LB
Construction Riveted
Rivet End To Centerline 0.752”
Connecting End To Centerline 0.803”
Transverse Pitch 0.712
Pin Diameter 0.200”
